RCA &ndash SOLID STATE POWER DEVICES &ndash TRANSISTORS TRIACS S (Catlett, VA)

RCA &ndash SOLID STATE POWER DEVICES &ndash TRANSISTORS TRIACS S

Local pick-up preferred (please call first) but will ship at the buyer s expenseKingston Books 15 IMG_7529Illustrated Charts Graphs Images of Device Packages RCA Devices Cross Reference Guide Terms and Symbols Operating Conditions Electrical Characteristics Maximum Ratings Mounting Hardware Heat Sink requirements.This Data Book contains complete technical information on the full line of RCA solid- state power devices power transistors power hybrid circuits Triacs and SCR s. A complete index of these types is included on the following pages. The index to devices is followed by a series of product matrix charts that provide a quick reference to key parameters and device packages to facilitate type selection. A cross-reference guide then indicates recommended RCA replacements for more than 2000 popular industry types. Next general operating considerations for solid-state power devices are discussed and symbols and special terms used to characterize these devices are listed.The DATABOOK also contains four major data sections that provide detailed ratings and characteristics for each of the various types of devices. For the convenience of the reader the Power Transistor Technical Data are further subdivided according to JEDEC Types Pro Electron Types and General Industry Types. Data pages for individual devices are given as nearly as possible in alpha-numerical sequence of the basic family type numbers. Because many devices may be included in the same basic family individual type numbers are not necessarily in sequence. If you don t find a type number where you expect it to be check the Index to Devices. General Information such as test circuits and waveforms dimensional outlines suggested mounting arrangements and lead forms for plastic packages are included in an Appendix at the back of the book. The Appendix also abstracts of relevant RCA application notes. The final pages contain listings of RCA sales offices manufacturers representatives and authorized distributors.Table of Contents (in brief)Index to Devices ..3Power-Transistor Product Classification Chart ..7Triac Product classification Chart ..13SCR Product Classification Chart ..16Guide to Product Selection Power-Transistor Product Matrix ..20Power-Transistors Technical Data JEDEC Types ..57Power Hybrid Circuits Technical Data ..535Triacs Technical Data ..541Silicon Controlled Rectifiers Technical Data ..609RCA High-Reliability Solid-State Power Devices ..665Appendix General Characteristics Test Circuits and Waveforms ..670RCA Sales Offices Authorized Distributors and Manufacturers Representatives ..697Paperback 703 pages
