Signetics Bipolar LSI Data Manual © 1984 (Catlett, VA)

Signetics Bipolar LSI Data Manual © 1984

Local pick-up preferred (please call first) but will ship at the buyer s expenseKingston Books 15 IMG_7522PREFACEThe LSI Division of Signetics designs and manufactures a broad range of Bipolar products that include both standard off-the-shelf devices as well as Semicustom parts. Our standard product line is headed by a unique Microcontroller that is specifically designed for high-speed control applications. With peripherals that are presently available and those planned for the future the Microcontroller provides a competitive edge in a complex controller system where speed flexibility reliability and economy are prime considerations.Semicustom products include gate arrays processed in one of four basic technologies Integrated Schottky Logic (ISL) Composite Cell Logic (CCL) Emitter Coupled Common Mode Logic (ECL CLM) and Complimentary Metal Oxide Silicon (CMOS). These products provide the designer with various combinations of speed packing densities I O capabilities and power dissipation. All semiconductor processes and tried-and-proven and Computer Aided Design (CAD) assures quick turnaround and error-free products.All standard and semicustom products are processed screened and tested to the highest quality standards and as indicated in the accompanying specifications many of the parts are qualified for Military applications.Signetics is continually developing new products to meet the changing needs of the world and the Marketing Department of the Bipolar LSI Division is continually searching for new and better ways of servicing our customers this manual being one of those ways. For further assistance please call upon us or your nearest Signetics Sales Office.Although every attempt has been made to ensure accuracy of the information contained herein Signetics assumes no liability for errors. Suggestions for improvement in this document are always welcome.Illustrated Tables Charts Summary of Instruction Sets Test Circuits AC DC Characteristics Timing Diagrams Absolute Maximum Ratings (voltage) Package and Pin designations Contents by Chapter (in brief)Ordering Information.....viProduct Status Definitions ..xSection 1 Indices Numeric Index ..1-1Section 2 Quality and Reliability Progress in Quality ..2-1Section 3 8X 300 Family - Index ..3-1Section 4 Product Support Index ..4-1Section 5 Software Support Index ..5-1Section 6 Sequencers Index ..6-1Section 7 Special Purpose Circuits Index ..7-1Section 8 Semicustom Service Index ..8-1Section 9 Semicustom Products Index ..9-1Section 10 Military Index ..10-1Section 11 Appendices Index ..11-1Section 12 Sales Office Office Listing ..12-1Paperback 325 pages
