Signetics &ndash FAST DATA MANUAL © 1984 (Catlett, VA)

Signetics &ndash FAST DATA MANUAL © 1984

Local pick-up preferred (please call first) but will ship at the buyer s expense.Kingston Books 15 IMG_7520Illustrated Charts Truth Tables Block Diagrams Device Pin-Outs Graphs (Propagation Delay vs. Load Capacitance Fall Time vs. Load Capacitance Output Low Characteristics Output High Characteristics) DC Electrical Characteristics AC Electrical Characteristics. Test Circuits and Waveforms Design Considerations (techniques to be considered when designing a high speed system) Data Sheet Specification GuideTypical Propagation Delay and Supply CurrentLogic SymbolsLogic Diagram (of the interior of a device)Absolute Maximum RatingsRecommended Operating ConditionsAbsolute Maximums Ratings Contents by Chapter (in brief)Introduction ..viiOrdering Information ..ixProduct Status and Definitions ..xSection 1. Indices Numerical Index ..1-4Section 2. Quality and Reliability ..2-1Section 3. Circuit Characteristics ..3-1Section 4. FAST User s Guide Data Sheet Specification Guide ..4-1Section 5. 54 74F Series Data Sheets ..5-1Section 6. FAST Application Notes Using FAST Logic Functions in Microprocessor Systems App Note 201 ..6-1Section 7. Surface Mounted Devices (SMD) ..7-1Section 8. Military Products ..8-1Section 9. Package Outlines ..9-1Section 10. Sales Offices ..10-1Signetics would like to thank you for your interest in our FASTtm product line. Because of its world wide customer acceptance FAST has become the preferred high-performance Logic family of the 80 s. We are proud to participate in and contribute to the dynamic growth of this market.Each data sheet contained in this manual is designed to stand alone and reflect the latest DC and AC specifications for a particular product. Features of this first Signetics FAST Data Manual include Availability and Functional Cross-Reference Guides A Circuit Characteristics Section A User s Guide Selected Application Notes A Chapter on Surface Mounted Devices (SMD) Introduction to the SO Surface-mounter package as a commercial option New FAST part types are being released monthly. As you see new product announcements you should contact your local Signetics sales office representative or authorized distributor or write Signetics c o Information Services at 811 East Arques Avenue P.O. Box 3409 Sunnyvale California 94088-3409 for the latest technical informationIn addition to FAST Signetics Logic Division offers a line of commercial Logic products which spans a wide speed power spectrum from 10k 100K ECL to HFC HCT High Speed CMOS and includes industry standard families such as 4000 Series CMOS 74 74LS and 74S Logic. Information on these product lines is also available from you nearest Signetics sales office sales representative or authorized distributor.Paperback 475 pages
