Signetics &ndash TTL DATA MANUAL © 1986 (Catlett, VA)

Signetics &ndash TTL DATA MANUAL © 1986

Local pick-up preferred (please call first) but will ship at the buyer s expense.Kingston Books 15 _IMG_7500Illustrated Sample Circuits RECOMMENDED OPERATING CONDITIONS AND ABSOLUTE MAXIMUM RATINGS Device pin-out Function Tables AC DC ELECTRICAL CHARACTERISTICS Test Circuits and Waveforms Typical Performance CharacteristicsPREFACESignetics would like to thank you for your interest in out products. This manual contains information and specifications on SSI MSI and LSI products in Standard Product families such as 7400 74S 74LS and 8t. Signetics offers a broad range of Logic Products besides those described in this data manual. Newer Random Logic families such as 74HC HCT and 74F are contained in other data manuals. 10K 100K ECL 4000 series CMOS. PROM RAM. And Application Specific Product specifications are contained in separate data manuals.This manual also includes -updated Technology and Function Cross Reference Guide-TTL User s Guide- an expanded chapter on SMD Technology- updated package informationAll references to military products has been deleted specifically to reflect government restrictions imposed via Revision C of MIL-STD 883 including the general provisions of Paragraph 1-2. Specifications for Signetics military products are available in the Signetics Military Products Data Manual.Signetics is continually developing new products. As you see new product announcements you should contact you local Signetics sales office representative or and authorized distributor or write Signetics c o Information Services at 8aa East Arques Avenue P.O Box 3409 Sunnyvale California 94088-3409 for the latest technical informationContents by Chapter (in brief)Logic ProductsPreface ..iProduct Status ..iiSection 1. Introduction Numerical Index ..1-3Section 2. Quality and Reliability Quality and Reliability Statement ..2-3Section 3. Military Information Military Information ..3-3Section 4. TTL User s Guide Product Information ..4-3Section 5. 74 Series Data Sheets ..5-3Section 6. 8T series Data Sheets ..6-3Section 7. LSI Products Data Sheets ..7-3Section 8 Surface Mounted IC s Surface Mounted IC s ..8-3Section 9. Package Outlines Introduction ..9-3Section 10. Sales Offices Office Listing ..10-3Paperback 900 pages
