NATIONAL SEMICONDUCTOR NSC800 MICROPROCESSOR FAMILY DATABOOK &co (Catlett, VA)

NATIONAL SEMICONDUCTOR NSC800 MICROPROCESSOR FAMILY DATABOOK &co

Local pick-up preferred (please call first) but will ship at the buyer s expense.Kingston Books 15 IMG_6760Illustrated Charts Graphs Sample Circuits Typical Performance Characteristics of each Device and Distinctive type (clock speed and material used to fabricate the chip) Physical Dimensions Package Outlines Timing Waveforms Device pinouts Block DiagramsThe NSC product family databook updates previous version handbooks data sheets and introduces new peripherals. It contains a new software section for the NSC800 CPU which contains the complete instruction set listed in alphabetical and numerical order as well as an instruction set index for the user s convenience. The databook provides the system designer with detailed technical descriptions of National s proprietary 8-bit CPU and its dedicated support peripherals. Also brief product overviews of NSC800 microprocessor based products such as National s CMOS industrial microcomputer CIM board and MA2000 macrocomponent family are included.Combining and improving upon the best features of the Z80 instruction set and the 8085 the NSC8000 offers designers superior performance I t uses the full Z80 instruction set to take advantage of the large base of available software utilizes a multiplexed bus structure for increased functionality thus reducing support circuits has 5 vectored priority interrupts for convenience and flexibility as well as many other unique and useful features.Since its introduction the NSC800 family of products has been put into use in a countless number of applications. The NSC8000 is supported by the Microcomputer Systems division the same group that introduced the industry-wide acclaimed Series 32000. The NSC800 product family is and will continue to be a solid foundation from which to base your system needsContents by Chapter (in brief)CPU PERIPHERALS EVALUATION BOARD LOGIC DEVICES MA2000 MACROCOMPONENT FAMILY APPENDICES PHYSICAL DIMENSIONS Paperback 217 pages
