Onan Technical Bulletin Alternating Current &ndash Single and Th (Catlett, VA)

Onan Technical Bulletin Alternating Current &ndash Single and Th

Local pick-up preferred (please call first) but will ship at the buyer s expenseKingston Books 15-IMG_7862Illustrated Charts Alternating Current Voltage Current Watt Power Factor Single Phase Loads Unbalanced Voltages Power Factor Correction Real Power-Uncorrected Real Power-Corrected.IntroductionThe alternating current (AC) and voltage output of a generator must be chosen to match the requirements of the load . Generators can supply either single phase or three phase (or both) AC at any common voltage from 120 to 600 volts. This bulletin will review the principles of alternating voltage current and power before providing details of single and three phase power.Electrical TerminologyVOLT (V) Voltage is the electrical pressure or force that causes current flow in a circuitAMP (A) Ampere is a rate of flow measurement f the current in a circuitPOWER (P) Power is the rate of doing work or the rate of expending energy. The unit of electrical power is the Watt expressed W VAWATT (W) Watt is the measurement of the electric power produced by a generator or consumed by a load. The work performed by the load is measured in watts.HERTZ (hz) The frequency of the number of complete cycles per second. There are two reversals of voltage and current in each cycle. Standard power line frequency domestically is 60 hertz and internationally is 50 hertz.PHASE Refers to a specific waveform of voltage or current. If voltage or current from two sources reach their positive peaks at the same time they are said to be in-phase . If two voltages peak at different times they are said to be out-of-phase . This term also is used to describe the voltage or current source as in single phase power or three phase power.POWER FACTOR (PF) Power Factor is the ratio of actual power delivered to a load measured in watts (w) to the apparent power expressed in volt-amperes (VA). The apparent power is calculated as the product of volts x amperes and is expressed as a decimal or percentage. Power factor is expressed PF kW (Actual) kVA (Apparent) Decimal %VAR Volt-Amperes Reactive VAR) is the component of volt-amperes which establishes the magnetic field that surrounds any coil.Table of Contents (in brief)INTRODUCTION .. (page 1)Electrical Terminology .. (page 1)Alternating Current ..(page 2)Technical Treatment of Power Factor .. (page 3)SINGLE AND THREE PHASE POWER .. (page 4)Single Phase 2-Wire 120VAC .. (page 4)Single Phase 3-Wire 120 240 VAC ..(page 4)Three-Phase Power .. (page 4)Three Phase Delta Systems .. (page 5)Three Phase Wye Systems .. (page 5)Three Phase 4 Wire Delta Systems .. (page 5)Single Phase Loads .. (page 6)Unbalanced Voltages .. (page 6)Power Factor .. (page 7)Power Factor of Commonly Used Electrical Equipment .. (page 7)Power Factor Correction .. (page 8)Real Power Uncorrected Factor .. (page 9)Real Power Corrected Power Factor .. (page 9)Rated Voltage _ Corrected Power Factor .. (page 10) LIST OF ILLUSTRATIONSFigure 1. One Complete Cycle .. (page 2)Figure 2. Voltage and Current Relationship .. (page 2)Figure 3. Power Factor and VARS vector .. (page 3)Figure 4. 120 240 Volts .. (page 4)Figure 5. 3-Phase 3-Wire Delta 240 VAC .. (page 4)Figure 6. 3-Phase 4-Wire Wye 208 120 VAC .. (page 5)Figure 7. 3-Phase Voltage Sine-Wave .. (page 5)Figure 8. 3-Phase 4-Wire Delta 120 240 VAC .. (page 5)Figure 9. Double Delta Configuration .. (page 6)Figure 10. Parallel Delta Configuration .. (page 6)Figure 11. Motor Power Factor Correction ..(page 8)Figure 12. Real Power Uncorrected Power Factor .. (page 9)Figure 13. Corrected Power Factor ..(page 9)Paperback 10 pages
