DELTROL CONTROLS &ndash RELAYS. ENGINEERING MANUAL © 1984 (Catlett, VA)

DELTROL CONTROLS &ndash RELAYS. ENGINEERING MANUAL © 1984

Local pick-up preferred (please call first) but will ship at the buyer s expenseKingston Books 15 IMG_7776Illustrated Charts Graphs Tables Pin Outs Schematic Diagrams Performance Data Specification Data Mechanical Drawings with Dimensions Base Diagrams Plug-In Relays Mounting Variations Accessories Socket Mounting Dimensions Contact Voltage and Current Ratings Contact Material Minimum expected contact and mechanical life Coil Voltage Terms and DefinitonsIndex Relay Type Description Page Number 100 General Purpose Relays for Light & Medium Power Loads 4100RF For 300 ohm Antenna Line 4100U 101U General Purpose Relays 6100UP 101UP 100U 101U Relays with Printed Circuit Termination 6105A 105 Relay with Indicator Lamp 8105MC 105 Relay with Hermetically Sealed Metal Can 8105G 105 Relay with Neoprene Rubber Seal 8105T Sensitive Plug-In Relay 10106P 161P 160 161 Relays with Printed Circuit Termination 12165 166 General Purpose Plug-In Relays W .187 OC Solder Termination & Dust Cover 14165A 166A 165 166 Relays with Lamp to Indicate Voltage Availability in Power Circuit 14165F 166F 165 166 Relays with Flanged Dust Cover 14165SM 166SM 165 166 Relays with Side Mounting Locating Tap and Screw 14165TM 166TM 165 166 Relays with Top Mounting Stud 14170 15 & 30 Amp Appliance-Rated & 30 Amp Tungsten-Rated relays 16171 15 & 30 Amp Industrial-Rated & 30 Amp Tungsten-Rated Relays 16100C Medium Duty Clappers 17900C Heavy Duty Clappers 17260 261 262 General Purpose Relays w 250 OC Terminals 18265F 266F 267F General Purpose Enclosed Relays w .250 OC Terminals 18265SM 266SM 267SM General Purpose Enclosed Relays w .250 OC Terminals & Side Mounting Locating Tap & Screw 18265TM 266TM 267TM General Purpose Enclosed Relays w .250 OC Terminals & Top Mounting Stud 18265B 266B 267B General Purpose Enclosed Relays w .250 OC Terminals & Manual Push-to-Test 18263 5 Amp General Purpose Open Plug-In Relay with .187 OC Solder Terminals 20268B 263 Relay with Dust Cover 20268F 263 Relay with Flanged Dust Cover 20268TM 263 Relay with Dust Cover & Top Mounting Stud 20268SM 263 Relay with Dust Cover & Side Mounting Locating Tab & Screw 20268B 263 Relay with Dust Cover & Manual Push-to-Test 20270 275F 25 35 Amp General Purpose Relays 22365 366 5 & 10 Amp General Purpose Relay w Larger Base & Dust Cover to Allow Room for Solid State Component 24404 410 2 & 10 Amp General Purpose High Current Printed Circuit Relay 26406 407 2 & 6 Amp Miniature Printed Circuit Relay 27416 10 Amp Miniature Printed Circuit Relay 28424 425 High Current 3 & 6 Amp Printed Circuit Relay 29870 871 20 Amp Power Relay 30900 Heavy Duty 30 amp Power Relays 32900-1C 900 Relay with SPDT Auxiliary Snap-Action Switch 32900OC 900 Relay with .250 OC Termination 32100ML 101ML UL and CSA Recognized General Purpose Magnetic Latching Relays 34102ML 100ML Relays Not UL and CSA Recognized 34103ML Polarized Magnetic Latching Relay 34105ML Plug-In Magnetic Latching Relay 36165ML 166ML Single and Dual Coil Magnetic Latching Relays 38165MLB 166MLB 165ML 166ML Relays with Magnetic Push-to-Reset 38BZ 50 60 Cycle AC Continuous or Intermittent Duty Buzzer 40105TD Octal Plug-In Time Delay Relays (Delay on Operate) 41105TD-R8 Plug-In 10 Amp Time Delay Relay (Delay on Release) 42105TD-R11 Octal Plug-In Time Delay Relays (Delay on Release 43166TD Quick Connect Plug-In Time Delay Relays (Delay on Operate) 44166TD-R Quick Connect Plug-In Time Delay Relays (Delay on Release) 45Terms & Definitions Time Delay Relays (Delay on Operate) 46Terms & Definitions Time Delay Relays (Delay on Release) 47 On CenterPaperback 47 pages
