Local pick-up preferred (please call first) but will ship at the buyers expense.Kingston Books 15 IMG_7606Heavily Illustrated Charts Tables Graphs Package pin-outs and Functions Four-Layer SCR Structure Pictorial Bipolar Model of an SCR Typical Output Circuit Input Protection Circuit Schematic System and Circuit Considerations Power Supply Over-Voltage Protection Package Dimensions and Mechanical Drawings Absolute Maximum Ratings AC and DC Electrical Characteristics Functional Descriptions Timing Diagrams Typical Pulse Based Telephone Circuit (with and without redial) Keypad Input Code Tone to Pulse Converter.Mitel Semiconductor has become the acclaimed leader in ISO-CMOSTM technology. With the establishment of licensees for the process and product line in the U.S. and Europe ISO-CMOS has become an industry standard. MITEL has applied this advanced technology to a broad range of low-power telecommunications integrated circuits thick-film hybrids and a select family of high-speed low-power microprocessor memory peripheral and octal interface components. Mitel products are manufactured to the highest quality standards with the use of MIL Standards 883B Test Methods and Procedures and 100% burn-in.Products are available from a number of worldwide factory locations and through an extensive international distributor network.Mitel currently has VLSI 2-micron ISO-CMOS products in development with R& D effort targeted at sub-micron line-width technology.Contents by Chapter (in brief)General Information An Introduction to ISO-CMOS TM Technology ..1-32. Telephone Set Components MSAN 103 Electronic Tone Ringer for Telephones ..2-33. DTMF Receiver ComponentsMSAN-102 Glossary of Digital Terms ..3-34. Line Interface and Switching ComponentsMSAN-102 Glossary of Digital Terms ..4-3Numerical Index (in brief. Only the first two listing shown)Data SheetsCM7050 MF Tone Generator ..4-95CM7291 DTMF Receiver Test Cassette ..3-73Application NotesMSAN-101 Applications of the MT8804A 8X4 Analog Switch Array ..4-11MSAN-102 Glossary of Digital Telecommunications Terms ..4-3MSAN-103 Electronic Tone Ringer to Replace the Telephone Bell ..2-3MSAN-104 An Introduction to ISO-CMOSTM Technology ..1-3MSAN-105 Application of the MT8860 Family of DTMF Receivers ..3-11MSAN-106 An Introduction to Mitel DTMF Receivers ..3-3MSAN-107 Understanding and Eliminating Latch-UP ..1-9Paperback 261 pages
