RCA Transient Voltage Suppression Devices _GE-MOV® Metal Oxid (Catlett, VA)

RCA Transient Voltage Suppression Devices _GE-MOV® Metal Oxid

Local pick-up preferred (please call first) but will ship at the buyer s expense.Kingston Books 15 IMG_7635Editors Susan A. Jerabek Sal J. CadellaContributing Authors Sebald John May Bernie I. Wolff Erwin Herr Roy Earl Francois D. MartzloffProduction & Graphics John J. GadzialaINTRODUCTIONGeneral Electric has been helping customers solve transient voltage problems since the introduction of the GE-MOV Varistors in 1972. The GE-MOV team is constantly researching the causes and effects of transients and developing new solutions to meet all types of transient suppression needs committed to innovation beyond today s technology.As the field of electronics has grown rapidly through the use of solid-state components so have the applications for surge suppressors to protect these transient sensitive devices. Innovations such as surface mount technology have also altered the demand profile by adding packaging considerations tp functional ones.As a result of innovation and research GE s line of metal oxide varistors has expanded to include surface mount devices new high energy packages and connector pin varistors and high temperature low profile varistors. These new products supplement the GE-MOV line of radial axial and high energy packaged varistors already the broadest in the industry.Just as the world of surge suppression has changed you will find many changes in the Fifth Edition Transient Voltage Suppression Manual new applications information updated product specifications expanded technical data on varistors and more. This manual reflects our commitment to excellence in transient voltage suppression technology and determination to give customers optimal design choices for their electronic component needs.Illustrated Charts Graphs Schematics and Waveforms Switch Arcing Voltage Escalation During Restrikes Transistor Switching Transient Transients on A.C. Power Lines Random Transients Amplitude and Frequency of Occurrence Duration Waveform and Source Impedance Telecommunication Line Transients Automobile Transients Effects of Voltage Transients Effects on Semiconductors Effects on Electromechanical Contacts Effects on Insulation Effects on Power Consumption Noise Generation Rate of Rise vs. Amplitude Transient Detection Previous and Future Surge Recordings Transient Testing and Standards Surge Voltages on Low-Voltage AC Power Circuits The Origins of Surge Voltages Transient Suppression Devices and Principles Filters Crowbar Devices Voltage Clamping Devices Selenium Cells Zener Diodes Varistors Silicone Carbide Varistors Metal-oxide Varistors Transient Suppressors Compared Ideal Device Zinc-Oxide Varistor Zener Crowbar (Zener-SCR Combination) Spark Gap Triggered Spark Gap Selenium Silicone Carbide Varistor. Failure Modes.TABLE OF CONTENTS (in briefVOLTAGE TRANSIENTS AN OVERVIEWRepeatable Transients ..1-1TRANSIENT SUPRESSION DEVICES AND PRINCIPLESTransient Suppression Devices ..2-1GE-MOV VARISTORS BASIC PROPERTIES TERMINOLOGY AND THEORYWhat is a Varistor ..3-1DESIGNING WITH GE VARISTORSSelecting the Varistor ..4-1SUPRESSION TELECOMMUNICATIONS SYSTEMSIntroduction ..5-1SUPPRESSION AUTOMOTIVE TRANSIENTSTransient Environment ..6-1VARISTOR TESTINGIntroduction ..7-1VARISTOR RELIABILITYIntroduction ..8-2GE-MOV VARISTOR SPECIFICATONSIntroduction ..9-1INDEX ..9-61Paperback 182 pages
