WESTERN DIGITAL COMMUNICATIONS PRODUCTS HANDBOOK © 1984 (Catlett, VA)

WESTERN DIGITAL COMMUNICATIONS PRODUCTS HANDBOOK © 1984

Local pick-up preferred (please call first) but will ship at the buyer s expenseKingston Books 15 IMG_7620Illustrated Charts Graphs Tables Device pin-outs and pin designations Block Diagrams Pin Definitions Diagnostic state Flow Chart Operating Characteristics (DC) Absolute Maximum Ratings Typical Characteristics Protocol Flow Charts Versabus Application of WD2840 Using Dual Port Memory Host Interface Host Interrupt and Driver Control Host Timing Clock and Arbitration Memory Array TAC Timing Local Network Access Tradeoffs A three-controller architecture Implementing TAC PC-LAN Simplified Block Diagram PC LAN System Ring Configuration.Functional Index (in brief)Local Area Network Products WD2840 Local Area Network Token Access Controller ..17SDLC HDLC X.25 Products Packet Network Interface (LAPB) ..87Asynchronous Bisynchronous Products WD2123 Dual Enhanced Universal Communications Element (DEUCE) ..177Data Security Products WD2001 WD2002 Data Encryption Device ..267Video Products WD8275 Programmable CDT Controller ..287Support Products WG1943 Dual Baud Rate Clock ..327Contents by Chapter (in brief)Functional Index ..viiNumerical Index ..ixSystem Product Quality Reliability ..1Quality Reliability to Leading Edge Technology ..5Announcing Burn-in Program Availability Warranties ..11Hi-Rel K Testing Program ..13Protocol Definitions ..15Local Area Network Products ..17SDLC HDLC X.25 Products ..87Asynchronous Bisynchronous Products ..177Data Security Products ..267Video Products ..287Support Products ..327Ordering Information ..383Package Diagrams ..384Pin Function Compatibility Guide ..386Storage Management Product Overview ..387Terms and Conditions ..389Bulletin New products soon to be announced.Advance Information This product has no been produced in volume and is subject to functional and timing revisions. Prior to designing with the product it is necessary to contact Western Digital Corporation for current information.Preliminary This product is limited production and may be subject to change after the device characterization has been completed. Prior to designing with the product it is necessary to contact Western Digital Corporation for current information.Final This product is in full production and intended for normal commercial applications. For military extended temperature burn-in or hi-rel applications contact Western Digital Corporation for information regarding further processing.Application Note This is specific application information related to the designated product(s). Paperback 390 pages
