MURATA ERIE FIXED AND VARIABLE CAPACITORS for HF VHF UHF and MICROWAVE Applications Catalog 58-03 1983Local pick- up preferred (please call first) but will ship at the buyer s expenseKingston Books 15 IMG_7616Illustrated Charts Graphs. Outstanding Characteristics Physical Characteristics Specifications Series Resonant Frequency vs. Capacitance Temperature Coefficient vs. Temperature Equivalent Series Resistance vs. Frequency RF Power Rating vs. Frequency Capacitance Change vs. Temperature Typical Q vs. Frequency VOLTAGE CONDITIONING DIELECTRIC WITHSTANDING VOLTS (DWV) INSULATION RESISTANCE (I R.) CAPACITANCE DISSIPATION FACTOR (DF) QUALITY FACTOR (Q) SOLDERABILITY LIFE (at max.rated temperature) RESONANCE VOLTAGE TEMPERATURE CHARACTERISTICS RESISTANCE TO SOLDER HEAT TEST DIMENSIONS in (mm) Average T.C. vs. TEMPERATURE C Typical Dissipation Factor vs. Temperature C Capacitance Drift vs. Capacitance Percent Capacitance Change vs. Temperature C Typical Insulation Resistance vs. Temperature C Typical Retrace Characteristics TRIMMER CAPACITORS (1.25 (pf.) to 120 (pf) Chip Trimmer Capacitor Construction GENERAL SPECIFICATIONS (Working Voltage 250 VDC Test Voltage 500 VDC I.R. > 106 megohms at 250 VDC. Torque 0.5 to 5.0 in. oz. Operating Temp. Range -65 C to 125 CTable of Contents (in brief)Glossary of Specialized Terms ..3Porcelain Ceramic Microwave Capacitors ..4-13Test Procedures ..14Murata Erie ATC Cross Reference ..15Glass Encapsulated Capacitors ..16-18Uniceram High-Q Miniature Ceramic Capacitors ..19-21Uniceram High-K Miniature Ceramic Capacitors ..22 23Introduction Trimmer Capacitors ..24Trimcaps TZ Series ..25-27Ceramic Trimmer Capacitors ..30 31Precision Miniature Air Variable Capacitors ..32 35Micro Miniature Sapphire Trimmers ..36.37General Test Procedures ..38 39GLOSSARY OF SPECIALIZED TERMS (in brief)DIELECTRIC DISSIPATION FACTOR ( DF ) QUALITY FACTOR ( Q ) WORKING (OR RATED ) VOLTAGE DIELECTRIC WITHSTANDING ( BREAKDOWN ) VOLTAGE INSULATION RESISTANCE (MEGOHMS) TEMPERATURE COEFFIICENT ( TC ) DRIFT VOLTAGE COEFFICIENT TERMINATION CHIP MONOLYTHIC OR MULTI-LAYER CAPACITOR TRIMMER CAPACITOR RANGE TUNING TORQUE RESOLUTION LINEARITY REVERSALS SEAL Paperback 39 pages
