NATIONAL SEMICONDUCTOR - CMOS INTEGRATED CIRCUITS © 1975 (Catlett, VA)

NATIONAL SEMICONDUCTOR - CMOS INTEGRATED CIRCUITS © 1975

Local pick-up preferred (please call first) but will ship at the buyer s expense.Kingston Books 15 IMG_7604Illustrated Charts Graphs Absolute maximum ratings General Description dc electrical characteristics ac electrical characteristics typical performance characteristics switching time waveforms and ac test circuits and switching time wveforms Truth Tables Device pin-outs (connection diagrams) Power considerations Application hints Typical applications INTRODUCTION TO 74C74C is a CMOS pin-for-pin function equivalent to the 7400 TTL family. This new concept in CMOS was designed with the engineer in mind. Strict design rules were adhered to in the input and output characteristics such as making all outputs capable of sinking 360 A (two LPT2L loads) and specifying all AC parameters at 50 pF loads. These consistent design rules will simplify system design by giving the engineer realistic and workable parameters. The engineer can take full advantage of his knowledge of the 7400 line and utilize the design tricks he has learned.For those designs that require 4000 Series National manufactures these circuits.Contents by Chapter (in brief)Introduction to 74C ..1CMOS Guide ..iv54C 74C Power Consumption Characteristics Guide ..vCMOS Cross Reference Guide ..vi74C DATA SHEETS IN NUMERICAL ORDER MM54C00 Quad 2-Input NAND Gate ..1CD4000 DATA SHEETS IN NUMERICAL ORDER CD4001M CD4001C Quadruple 2-Input NOR Gate ..1-21APPLICATION NOTES BRIEFS AN-77 CMOS The Ideal Logic Family ..209CMOS Packages ..244Ordering Information ..246Paperback 246 pages
