Good Condition - ARCHER (Radio Shack) SEMICONDUCTOR REFERENCE HA (Catlett, VA)

Good Condition - ARCHER (Radio Shack) SEMICONDUCTOR REFERENCE HA

Local pick-up preferred (please call first) but will ship at the buyer s expenseKingston Books 15 IMG_7597Illustrated Charts Graphs Tables Package pin-outs Pin Configuration electrical characteristics Schematics and connection diagrams absolute maximum ratings recommended operating conditions switching characteristics logic diagrams case style chart symbols How to use this Book Silicone or Germanium Operating Considerations Handling of Integrated Circuits and Transistors Silicon Rectifiers About case dimensions General Precautions In-Circuit Testing Out-Of-Circuit Testing INTRODUCTIONThe ARCHER Semiconductor handbook offers the hobbyist experimenter student service technicians and engineering personnel a hand transistor cross reference guide as well as complete technical information about all the ARCHER Semiconductor devices.The 38 ARCHER transistors are cross referenced for substitutions or replacement of over 30 000 commercial transistor types. Radio Shack takes great pride in offering top quality devices with known JEDEC EIA or manufacturer s numbers for each ARCHER device.The replacement listings are based on careful analysis of important parameters of the listed devices. The information The information has been carefully compiled and cross referenced with the published specifications of each device noted. Each ARCHER replacement should meet or exceed the required parameters. However due to the differences in Quality Control and Manufacturing procedures (which often allow for a result in broad parameter variations) and because many of the ARCHER devices are capable of better performance than the original Radio Shack does not guarantee nor does it imply that the listed items will provide an exact replacement in every instance. Therefore we recommend that you check the voltage and current requirements of the circuit (and other pertinent specifications) before replacement and compare with the specifications) before replacement and compare with the specifications listed for that particular ARCHER device.Table of ContentsINTRODUCTION ..3HOW TO USE THIS BOOK ..3SILICONE OR GERMANIUM ..4HANDLING OF TRANSISTORS AND INTEGRATED CIRCUITS ..5SILICONE RECTIFIERS ..5SOLDERING PRECAUTIONS ..6ABOUT CASE DIMENSINS ..6GENERAL PRECAUTIONS ..7TESTING A TRANSISTOR ..8-9BI-POLAR TRANSISTORS ..10-11FIELD EFFECT TRANSISTORS ..12UNIJUNCTION TRANSISTORS ..12INTEGRATED CIRCUITS ..13-50THYRISTORS-SCR-TRIACS ..51DIODES-ZENERS-BRIDGES ..52LIGHT EMITING DIODES ..53-59CADIMUM SULFIDE PHOTOCELL ..60SELENIUM SOLAR CELL ..60QUICK REFERENCE CASE STYLE ..61-63SYMBOLS AND ELECTRICAL CHARACTERISTICS ..65-67CROSS-REFERENCE SUBSTITUTION LISTINGS ..68-168GLOSSARY OF WORDS SYMBOLS AND ABBREVIATIONS ..169-174Paperback 176 pages
