Texas Instruments - The TTL Data Book &ndash Volume 1 &ndash Ind (Catlett, VA)

Texas Instruments - The TTL Data Book &ndash Volume 1 &ndash Ind

Local pick-up preferred (please call first) but will ship at the buyer s expense.Kingston Books 15 - IMG_7596Heavily Illustrated Charts Graphs Tables Device pin-outs Parameter measurement information Functional block diagrams Absolute maximum ratings Recommended operating conditions Programming parameters Logic diagrams Electrical characteristics Switching characteristics Programming waveforms Input line select Product Line Selection.Contents by Chapter (in brief)Alphanumeric Index and General InformationFunctional IndexProduct GuideExplanation of New Logic SymbolsOrdering Instructions and Mechanical DataINTRODUCTIONTexas Instruments presents important technical information on the industries broadest and most advanced families of TTL integrated circuits in the TTL data books volumes 1 through 4.The TTL Data Book Volume 1 includes Alphanumeric and Functional Indexes to all bipolar digital devices available or under development showing the current technologies for each type. Logic symbols prepared in anticipation of IEEE Std. 91- 1982 and pin assignments for all bipolar devices are shown in the Product guide section together with typical performance data and chip carrier information. Package dimensions are given in the Mechanical Data section.The TTL Data book Volume 2 comprehends complete specifications of five series of Transistor-Transistor-Logic Circuits (Series 54L) Low-Power Schottky (Series) 54ALS 74ALS and Advanced Schottky TTL (54S 74S) devices.The TTL Data Book Volume 3 contains complete specifications on the most advanced families of TTL integrated circuits Advanced Low-Power Schottky (Series 54ALS 74ALS) and Advanced Schottky (SERIES 54AS 74AS) with circuits capable of twice the data throughput compared to Low-Power Schottky TTL (Series 54LS 74LS) and Schottky TTL (54S 74S) devices.The TTL Data Book Volume 4 describes a series of high-complexity bipolar digital building blocks and support functions designed specifically for implementing high-performance Computer or Controller systems. Included are specification for high-performance Schottky TTL memories (RAMs ROMs PROMs and FIFOs) and for Field Programmable Logic devices.The TTL data books volume 1 through 4 will be a meaningful addition to your technical library. They replace all previous versions of The TTL Data Book The ALS AS Logic Circuits Data Book The Bipolar Microprocessor Components Data Book Integrated Schottky-Barrier diode-clamped transistor is patented by Texas Instruments U.S Patent Number 3 463 975.Paperback 316 pages
