SGS Technology and Service &ndash Databook 1st Ed. HIGH SPEED C (Catlett, VA)

SGS Technology and Service &ndash Databook 1st Ed. HIGH SPEED C

Local pick-up preferred (please call first) but will ship at the buyer s expense.Kingston Books 15 IMG_7595Illustrated Charts Graphs Device Package pin-outs (pin numbers with signal designations with corresponding inputs outputs and Function designations) Input output protection Operating voltage range of 2 to 6 volts Absolute Maximum Ratings Recommended Operating Conditions Pin Connections displaying interior logic gates DC specifications AC Electrical Characteristics Input and Output Circuit Equivalents Package Types (Plastic Ceramic Chip Carrier) Logic Diagrams Truth Tables IDENTITYLate in 1957 SGS was founded around a team of researchers who were already carrying out pioneer work in the field of semiconductors. From that small nucleus the company has evolved into a Group of Companies operating on a worldwide basis as a broad range semiconductor producer with billings well over a quarter of a billion dollars and employing about 7500 people.The SGS Group of Companies has now reached a total of 10 subsidiaries located in France Germany Italy Malta Malaysia Singapore Sweden Switzerland United Kingdom and the USA.To go with its logo the company has chosen the motto Technology and Service underlining the accent given to the development of state of the art technologies and the corporate commitment to offer customers the best quality and service in the industry.TABLE OF CONTENTS (in brief)SGS AN INTRODUCTION ..4ALPHA NUMERIC INDEX ..8FUNCTION SELECTOR GUIDE ..13GENERAL AND APPLICATION INFORMATION ..41DATA SHEETS ..53PACKAGES ..555RELIABILITY REPORT ..559Paperback 575 pages
