FAIRCHILD - TTL DATA BOOK ©1978 (Catlett, VA)

FAIRCHILD - TTL DATA BOOK ©1978

Local pick-up preferred (please call first) but will ship at the buyer s expenseKingston Books 15 IMG_7560Illustrated Charts Graphs Tables Device pin-outs Logic Diagrams Logic Symbols and Terminology Input and Output Characteristics Absolute Maximum Ratings Recommended Operating Conditions Characteristics by Family and Temperature Truth Tables AC and DC Characteristics Clock Waveforms Ordering Codes for Commercial Grade and Military Grade Packages.INTRODUCTIONThis TTL DATA BOOK is a complete reference source for all Fairchild semiconductor SSI MSI TTL products (except Fairchild Advanced Schottky TTL FAST devices). It is organized into the following sections Section 1 Product Indices and Selection GuidesSection 2 TTL CharacteristicsSection 3 Loading Specifications and WaveformsSection 4 through 7 Family Data SheetsSection 8 Other Digital ProductsSection 9 Ordering Information and Package OutlinesSection 10 Fairchild Field Sales Offices Representatives and DiostributorsContents by Chapter (in brief)SECTION 1 PRODUCT INDICES AND SELECTIOM GUIDES Indices 54 74 Family TTL ..1-3SECTION 2 TTL CHARACTERISTICS Glossary ..2-3SECTION 3 LOADING SPECIFICATIONS AND WAVEFPR S Unit Loads (U.L.) ..3-3SECTION 4 54 74 FAMILY DATA SHEETS ..4-3SECTION 5 9- FAMILY DATA SHEETS ..5-3SECTION 6 93XX FAMILY DATA SHEETS ..6-3SECTION 7 96xx FAMILY DATA SHEETS ..7-3SECTION 8 OTHER DIGITAL PRODUCTS RTL Micrologic and CTL Counting Micrologic Elements ..8-3SECTION 9 ORDERING INFORMATION AND PACKAGE OUTLINES Ordering Information ..9-3SECTION 10 FAIRCHILD FIELD SALES OFFICES REPRESENTATIVES AND DISTRIBUTORS ..10-3Paperback 738 pages
