Fairchild Advanced Schottky TTL (FAST) (Catlett, VA)

Fairchild Advanced Schottky TTL (FAST)

Local pick-up preferred (please call first) but will ship at the buyer s expenseKingston Books 15 IMG_7553Illustrated Charts Graphs Basic FAST Gate Schematic Transistor Functions at Room and High Temperatures Propagation Delay tPLH vs Vcc Propagation Delay vs. Load Capacitance Transition Time vs. Load Capacitance Output LOW Characteristics OUTPUT HIGH Characteristics Input Characteristic Input Loading Fan-Out BSOLUTE Maximum Ratings Recommended Operating Conditions 54F 74F Family DC Characteristics AC Loading and Waveforms Propagation Delays from Rising-Edge Clock or Enable Propagation Delays from Set and Clear (or Reset) Enable and Disable RTest Loads for 3-State Outputs Device pin-outs showing the schematic representations of the internal circuitry of the chip AC and DC Characteristics of the chips Truth TableFAST TechnologyFast is an acronym for Fairchild Advanced Schottky TTL. FAST circuits are made with the advanced Isoplanar II process which produces transistors with a very high well-controlled switching speeds in excess of 5 GHz. Extremely small parasitic capacitances and ft in excess of 5 GHz. Isoplanar is an established Fairchild process used for years in the manufacture of bipolar memories. CMOS subnanosecond ECL and I3L tm (Isoplanar Integrated Injection Logic) LSI devices.In the Isoplanar process components are isolated by a selectively grown thick oxide rather than the P isolation region used in the Planar process. Since this oxide needs no separation from the base-collector regions component and chip sizes are substantially reduced. The base and emitter ends the device areas terminate in the oxide wall masks can thus overlap the device area into the isolation oxide. This overlap feature eliminates the extremely close tolerances normally required for base and emitter masking and the standard photolithographic process can be used.Contents by Chapter (in brief)Section 1 Product Index ..1-3Section 2 Family Characteristics FAST Technology ..2-3Section 3 Circuit Select Guides Gates ..3-3Section 4 Data Sheets ..4-3Section 5 Ordering Information and Package Outlines Ordering Information ..5-3Section 6 Sales Offices Representatives and Distributor LocationsPaperback 194 pages
