FAIRCHILD &ndash TTL DATA BOOK © 1978 (Catlett, VA)

FAIRCHILD &ndash TTL DATA BOOK © 1978

Local pick-up preferred (please call first) but will ship at the buyer s expenseKingston Books 15 IMG_7552INTRODUCTIONThis TTL Data Book is a complete reference source for all Fairchild semiconductor SSL MSI TTL products (except Fairchild Advanced Schottky TTL FAST devices). It is organized into the following sections Section 1 Product Indices and Selection GuidesSection 2 TTL CharacteristicsSection 3 - Loading Specifications and WaveformsSection 4 through 7 Family Dataa SheetsSection 8 Other Digital ProductsSection 9 Ordering Information and Package OutlinesSection 10 Fairchild Field Sales Offices Representatives and DistributorsIllustrated Charts Graphs Input and Output Characteristics Thermal Resistances by Device Type Flatpack Ceramic Dip Plastic Sample Circuits Loading and Fan-out Specifications Absolute Maximum Ratings Recommended Operating Conditions Waveforms DC and AC Characteristics Device pin-outs Logic Diagrams Function Tables Truth TablesContents by Chapter (in brief)SECTION 1. PRODUCT INDICES AND SELECTION GUIDES Indices 54 74 Family TTL ..1-3 Selection Guides SSI Functions ..1-12SECTION 2. TTL CHARACTERISTICS Glossary ..2-3SECTION 3. LOADING SPCIFICATIONS AND WAVEFORMS Unit Loads (U.L.) ..3-3SECTION 4. 54 74 FAMILY DATA SHEETS ..4-3SECTION 5. 9- FAMILY DATA SHEETS ..5-3SECTION 6. 93- FAMILY DATA SHEETS ..6-3SECTION 7. 96- FAMILY DATA SHEETS ..7-3SECTION 8. OTHER DIGITAL PRODUCTS RTL Micrologic and CTL Counting Micrologic Elements ..8-3SECTION 9. Ordering Information ..9-3SECTION 10. FAIRCHILD FIELD SALES OFFICES REPRESENTATIVES AND DISTRIBUTORS ..10-3 Paperback 745 pages
